PAF500F24-12，PAF500F48-5，TDK-LAMBDA 开关电源
详细信息
| | 品牌：LAMBDA | | 加工定制：否 | | 型号：PAF500F48-12 | |
| | 输入电压：DC19-36/36-72V V | | 输出电压：DC5-48 V | | 输出功率：500-700 W | |
| |
PAF500F24 |
PAF500F48 |
PAF600F24 |
PAF600F48 |
PAF700F48 |
| Output Voltage |
12V |
28V |
3.3V |
5V |
12V |
28V |
12V |
28V |
12V |
28V |
12V |
28V |
| Input voltage range |
19-36VDC |
18-36VDC |
36-76VDC |
20-36VDC |
19-36VDC |
36-76VDC |
| Output voltage range |
-40～ +10% |
-40～ +20% |
-40～ +10% |
-40～ +10% |
-40～ +15% |
| Parallel operation |
Possibe |
| line regulation |
24mV |
56mV |
10mV |
24mV |
56mV |
24mV |
56mV |
24mV |
56mV |
24mV |
56mV |
| within nominal input voltage range at constant load |
| Load regulation |
24mV |
56mV |
10mV |
24mV |
56mV |
24mV |
56mV |
24mV |
56mV |
24mV |
56mV |
| no load to full load at constant input voltage |
| Cooling |
Conduction cooling (Heatsink & airflow has to chosen according to instruction manual ) |
| Operating ambient temperature |
Baseplate temperature : -40～+85°C
Ambient temperature : above -40°C |
| Withstand voltage |
Input-output : 1.5kVDC, Input-baseplate 1.5kVDC
input-baseplate 500VDC, output-chassis : for 1min |
| |
|
|
|
| Fanctions |
Over voltage protection,Over current protection,Remote on/off control |
Product lineup
| Model name |
Output Voltage |
Output Current |
Output Power |
| PAF500F24-12 |
12V |
42A |
504W |
| PAF500F24-28 |
28V |
18A |
| PAF500F48-3.3 |
3.3V |
80.0A |
264W |
| PAF500F48-5 |
5V |
80.0A |
400W |
| PAF500F48-12 |
12V |
42.0A |
504W |
| PAF500F48-28 |
28V |
18.0A |
| PAF600F24-12 |
12V |
50A |
600W |
| PAF600F24-28 |
28V |
21.5A |
602W |
| PAF600F48-12 |
12V |
50A |
600W |
| PAF600F48-28 |
28V |
21.5A |
602W |
| PAF700F48-12 |
12V |
58.5A |
702W |
| PAF700F48-28 |
28V |
25A |
700W |
