360W系列封闭式开关电源AQF360E-24S AQF360E-12SS
详细信息
| | 品牌：ARCH | | 类型：AC/DC电源 | | 输入电压：AC85-264V/ DC88-370V V | |
| | 输出功率：360 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC12--48 V | | 工作效率：92 % | | 型号：AQF360E-48S AQF360E-36 | |
| 360W系列封闭式开关电源AQF360E-24S AQF360E-12S AQF360E-48S AQF360E-36S |
| |
| Feature |
|
|
| |
紧凑的尺寸为6.8 x 3.2 x 2.1英寸
包装：封闭
工作温度：-10〜70度
90〜264 VAC通用输入范围
与P.F.C. 函数，PF> 0.95
内置12 VDC风扇冷却
240W对流，无风扇
保护：过载/过压/过热/短路通过自动恢复
漏电流<300uA
功率密度和效率93％
|
|
| |
| Specification |
| |
1.规格均在标称输入电压，+ 25°C的预热时间后有效
除非另有说明。
2.使用0.1U 50V // 47U 50V陶瓷电容测量。 交叉输出 |
| |
Input Specification |
|
| |
Characteristics |
Conditions |
|
| |
Voltage Range |
AC IN |
90 ~ 264 VAC |
|
| |
DC IN |
100 ~ 370 VDC |
|
| |
Frequency |
47 ~ 63 Hz |
|
| |
|
|
|
|
|
| |
|
|
| |
|
|
|
|
|
| |
General Specification |
|
| |
Characteristics |
Conditions |
|
| |
Switching Frequency |
75K Hz (typ.) |
|
| |
Isolation Voltage (Input to Output) |
4000 VAC (min.) |
|
| |
Operating Temperature |
-10 °C to +70 °C (with derating) |
|
| |
Storage Temperature |
-25°C to +85°C |
|
| |
Humidity |
95% RH (max.) |
|
| |
Cooling |
Cooling by Built-in DC FAN |
|
| |
|
|
|
|
|
| |
Physical Specification |
|
| |
Characteristics |
Conditions |
|
| |
Dimension (Tolerance ±0.5) |
172.7 x 81.3 x 53.3 mm |
|
| |
6.8 x 3.2 x 2.1 inches |
|
| |
Weight |
729 g |
|
| |
Case Material |
Enclosed |
|
| |
|
|
|
|
|
|
|
| |
Model |
|
| |
|
|
| |
|
|
| |
| ModelNo. |
InputRange |
OutputVoltage |
OutputCurrent |
Eff |
| (V.AC ) |
(V.DC ) |
(mA ) |
(效率) |
| Single Output Models |
| AQF360E-12S |
90 ~ 264 VAC |
12 |
30,000 |
89 |
| AQF360E-24S |
90 ~ 264 VAC |
24 |
15,000 |
91 |
| AQF360E-36S |
90 ~ 264 VAC |
36 |
10,000 |
92 |
| AQF360E-48S |
90 ~ 264 VAC |
48 |
7500 |
93 |
|
|
|
