LWT15H-5FF，LWT15H-522，AC-DC TDK-LAMBDA 开关电源
详细信息
| | 品牌：LAMBDA | | 类型：AC/DC电源 | | 输入电压：AC90-264V V | |
| | 输出功率：15-50W W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：5V +/-15V V | | 工作效率：85 % | | 型号：LWT15H-525 | |
TDK-LAMBDA开关电源
| Input voltage range |
AC85～265V (47～440Hz) DC110～330V universal input |
| Output voltage range |
CH1 : +5%, CH2 : Fixed |
| Cooling |
Convection cooling |
Operating ambient
temperature |
0～+60°C
Output derating, 0～+40°C :100%, +50°C :80%, +60°C : 60% |
| Withstand voltage |
Input-output : 3kVAC, input-FG : 2kVAC for 1min. |
| Safety standard |
|
| EMI |
Conforms to FCC class B and VDE class B |
| Functions |
Over voltage protection (CH1), Over current protection |
Product lineup
| Model name |
CH |
Nominal output voltage |
Max. output current |
Max. output power |
Total max.
output power |
| LWT15H |
LWT15H-5FF |
CH1 |
5V |
0.5-3.0A |
15.0W |
17.0W |
| CH2 |
+15V |
0.6A |
9.0W |
| CH3 |
-15V |
0.4A |
6.0W |
| LWT15H-522 |
CH1 |
5V |
0.5-3.0A |
15.0W |
17.0W |
| CH2 |
+12V |
0.6A |
7.2W |
| CH3 |
-12V |
0.4A |
4.8W |
| LWT15H-525 |
CH1 |
5V |
0.5-3.0A |
15.0W |
17.0W |
| CH2 |
+12V |
0.6A |
7.2W |
| CH3 |
-5V |
0.4A |
2.0W |
| LWT30H |
LWT30H-5FF |
CH1 |
5V |
0.7-5.0A |
25.0W |
30.0W |
| CH2 |
+15V |
1.2A |
18.0W |
| CH3 |
-15V |
0.6A |
9.0W |
| LWT30H-522 |
CH1 |
5V |
0.7-5.0A |
25.0W |
30.0W |
| CH2 |
+12V |
1.2A |
14.4W |
| CH3 |
-12V |
0.6A |
7.2W |
| LWT30H-525 |
CH1 |
5V |
0.7-5.0A |
25.0W |
30.0W |
| CH2 |
+12V |
1.2A |
14.4W |
| CH3 |
-5V |
0.6A |
3.0W |
| LWT50H |
LWT50H-5FF |
CH1 |
5V |
1.0-8.0A |
40.0W |
50.0W |
| CH2 |
+15V |
1.5A |
22.5W |
| CH3 |
-15V |
1.0A |
15.0W |
| LWT50H-522 |
CH1 |
5V |
1.0-8.0A |
40.0W |
50.0W |
| CH2 |
+12V |
1.5A |
18.0W |
| CH3 |
-12V |
1.0A |
12.0W |
| LWT50H-525 |
CH1 |
5V |
1.0-8.0A |
40.0W |
50.0W |
| CH2 |
+12V |
1.5A |
18.0W |
| CH3 |
-5V |
1.0A |
5.0W |
As for the mention contents of this page, understand beforehand because it sometimes changes.
