详细信息
品牌：LEM 加工定制：是 型号：HLSR10-P,HLSR50-P 制作工艺：薄膜 输出信号：模拟型 材料：金属 材料物理性质：导体 材料晶体结构：多晶 线性度：1 %F.S 迟滞：1 %F.S 重复性：2 %F.S HLSR Series
为您设计的
Main characteristics:
主要特点：
• Really cost effective
• 5 ranges: 10 ARMS, 20 ARMS, 32 ARMS, 40 ARMS, 50 ARMS
•5范围：10A，20A，32A，40A，50A
• Access to voltage reference
•获得参考电压
• Low offset & gain drift
•低偏移和增益漂移
• Short response time: 2.5 µs
•响应时间短：2.5µ的
• Compact Unique design for all the models
•紧凑独特的设计
• Only 3.87 cm2 as surface occupied on the PCB
•只有3.87平方厘米为占用印刷电路板表面
• Really flat: 12 mm height only!
•真的是平的：12毫米高度！
• Measuring range up to 2.5 x IPN
•测量范围2.5×IPN
• High accuracy @ 25°C: +/- 1% of IPN; @ 105°C: +/- 3.4% of IPN
•误差@ 25°C + / - 1%的IPN；@ 105°C + / - 3.4%
• Creepage & clearance distances: 8 mm + CTI 600
•间隙距离：8毫米+ CTI 600
• 5 years warranty
•5年保修
Features:- DC, AC pulse currents' measurements with galvanic isolation
- Single supply +5 V or +3.3 V (2 different models)
- Isolation test voltage: 4.3 KVRMS / 50Hz / 1min
- Through hole (-P) or surface (-SM) PCB mounting models
- Voltage output (0.8 V @ IPN)
- Fixed offset and gain
- Operating temperature range: -40 to +105°C
- Light: 5.5 g
- Open loop technology combined with ASIC
- EN50178 for industrial applications such as:
- Home appliances
- Variable speed drives
- UPS's
- SMPS's
- Welding applications
- Air conditioners
- Current monitoring
- Solar panels inverters (MPPT)
- Combiner box
- UL 508 (UR marking)
- European Directive EMC 2004 / 108 / EEC: CE Marking
- Using UL94-VO recognized materials
- Low voltage directive 2006 / 95 / EEC
- IEC 61010-1 Safety
•双极电流时，单提供0 / + 5 V或0 / + 3.3 V测量
• HLSR brings an additional pin, at the output for more flexibility in applications. This pin provides access to the internal voltage reference of the ASIC which can then be fed to the reference of an A/D converter (Analog Digital) This extra pin can also receive the internal reference (from 0.5 V to 2.65 V) of the DSP (Digital Signal Processor) or A/D converters commonly used in power electronics, allowing cancellation of the reference temperature drift.
•HLSR带来了一个额外的引脚，在输出中的应用程序更加灵活。此引脚提供了访问的ASIC可以输送到一个A / D转换器参考内部参考电压（模拟数字）这额外的引脚也可以得到内部参考（从0.5 V至2.65 V）的DSP（数号处理器）或A / D转换器常用电力电子，允许参考温度漂移消除。
• Transducers sample kits are available for each model. Each kit contains 5 transducers of the same model inside in order to allow a qualification tests' campaign
•换能器样品盒可用于每个模型。每个套件包含5阶传感器在相同的模型允许一个合格试验”活动
• A special version called "SP14" is available on request with 14 mm as creepage & clearance distances
•“SP14”是根据要求提供14毫米的间隙距离
• The version called "SP33" is the model to be power supplied in single +3.3 V
•为“sp33”是在单+ 3.3 V供电模式
Product search results Model Primary
Nominal
ValueMeasuring
RangeSecondary
SignalSupply
Voltage (V)Accuracy (误差) Mounting HLSR 10-P 10 A 25 A 0.8 V 5-5 Uni 1 PCB HLSR 10-P KIT 5 P 10 A 25 A 0.8 V 5-5 Uni 1 PCB HLSR 10-P/SP33 10 A 25 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 10-P/SP33 KIT 5 P 10 A 25 A 0.46 V 3.3-3.3 Uni 0.9 PCB HLSR 10-SM 10 A 25 A 0.8 V 5-5 Uni 1 PCB HLSR 10-SM KIT 5 P 10 A 25 A 0.8 V 5-5 Uni 1 PCB HLSR 10-SM/SP33 10 A 25 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 10-SM/SP33 KIT 5 P 10 A 25 A 0.46 V 3.3-3.3 Uni 0.9 PCB HLSR 20-P 20 A 50 A 0.8 V 5-5 Uni 1 PCB HLSR 20-P KIT 5 P 20 A 50 A 0.8 V 5-5 Uni 1 PCB HLSR 20-P/SP33 20 A 50 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 20-P/SP33 KIT 5 P 20 A 50 A 0.46 V 3.3-3.3 Uni 0.9 PCB HLSR 20-SM 20 A 50 A 0.8 V 5-5 Uni 1 PCB HLSR 20-SM KIT 5 P 20 A 50 A 0.8 V 5-5 Uni 1 PCB HLSR 20-SM/SP33 20 A 50 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 20-SM/SP33 KIT 5 P 20 A 50 A 0.46 V 3.3-3.3 Uni 0.9 PCB HLSR 32-P 32 A 80 A 0.8 V 5-5 Uni 1 PCB HLSR 32-P/SP33 32 A 80 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 32-SM 32 A 80 A 0.8 V 5-5 Uni 1 PCB HLSR 32-SM/SP33 32 A 80 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 40-P 40 A 100 A 0.8 V 5-5 Uni 1 PCB HLSR 40-P KIT 5 P 40 A 100 A 0.8 V 5-5 Uni 1 PCB HLSR 40-P/SP33 40 A 100 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 40-P/SP33 KIT 5 P 40 A 100 A 0.46 V 3.3-3.3 Uni 0.9 PCB HLSR 40-SM 40 A 100 A 0.8 V 5-5 Uni 1 PCB HLSR 40-SM KIT 5 P 40 A 100 A 0.8 V 5-5 Uni 1 PCB HLSR 40-SM/SP33 40 A 100 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 40-SM/SP33 KIT 5 P 40 A 100 A 0.46 V 3.3-3.3 Uni 0.9 PCB HLSR 50-P 50 A 125 A 0.8 V 5-5 Uni 1 PCB HLSR 50-P KIT 5 P 50 A 125 A 0.8 V 5-5 Uni 1 PCB HLSR 50-P/SP33 50 A 125 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 50-P/SP33 KIT 5 P 50 A 125 A 0.46 V 3.3-3.3 Uni 0.9 PCB HLSR 50-SM 50 A 125 A 0.8 V 5-5 Uni 1 PCB HLSR 50-SM KIT 5 P 50 A 125 A 0.8 V 5-5 Uni 1 PCB HLSR 50-SM/SP33 50 A 125 A 0.46 V 3.3-3.3 Uni 1 PCB HLSR 50-SM/SP33 KIT 5 P 50 A 125 A 0.46 V 3.3-3.3 Uni 0.9 PCB -
