ARCHAC/DC电源模块AHC08系列AHC08-5S-A2_西安浩南电子科技有限公司

ARCHAC/DC电源模块AHC08系列AHC08-5S-A2

详细信息

ARCH AC/DC电源模块AHC08系列AHC08-5S-A2 AHC08-9S-A2 AHC08-12S-A5 AHC08-12S7.5S-A5 AHC08-24S-A2
小尺寸:2.0 x 1.0 x0.75英寸

包装:PCB安装模块

操作温度:-40 ~ 70度

90~305 VAC通用输入范围

控制输出和低纹波和噪声

空载功率< 0.3W

单、双输出

小尺寸为ahc5w，功率为8w

Specification
1.All specifications valid at nominal input voltage,full load and +25°C after warm-up time unless otherwise stated. 2.Measured with 0.1U 50V // 47U 50V Ceramic Cap. Cross to output

Input Specification
Characteristics	Conditions
Voltage Range	AC IN	90 ~ 305 VAC
Voltage Range	DC IN	120 ~ 430 VDC
Frequency	47 ~ 440 Hz

Output Specification
Characteristics	Conditions
Output Power	8 Watt (max.)
Voltage Accuracy (Full Load and Nominal Vin)	Single:
	Dual:

Minimum Load (LL TO HL at Full Load)	S
Line Regulation (balanced)	Single:		(typ.)
	Dual:

Load Regulation (balanced)	Single:		(typ.)
	Dual:

Ripple (20MHz bandwidth)	24S:<150mV (Vp-p)		(max.)
Ripple (20MHz bandwidth)	others:<100mV (Vp-p)		(max.)
Noise (20MHz bandwidth)	24S:<200mV (Vp-p)		(max.)
Noise (20MHz bandwidth)	others:<150mV (Vp-p)		(max.)
Temperature Coefficient	±0.02%/ °C (max.)
Short Circuit Protection	Hiccup mode, indefinite (automatic recovery)

General Specification
Characteristics	Conditions
Switching Frequency	(typ.)
Isolation Voltage (Input to Output)	3000 VAC (min.)
Operating Temperature	-40 °C to +70°C (with derating)
Storage Temperature	-40°C to +85°C
Humidity	95% RH (max.)
Cooling	Free-air convection

Physical Specification
Characteristics	Conditions
Dimension (Tolerance ±0.5)	52.2 x 26.8 x 19.0 mm
Dimension (Tolerance ±0.5)	2.055 x 1.055 x 0.75 inches
Weight	35 g
Case Material	Plastic resin (flammability to UL 94V-0)
